SGSK

Slant Bed CNC Lathe TCK56

Серия: TCK

Max. swing diameter over bed 560mm

Max. swing over cross slide: 350mm

Processing length 500mm

Spindle speeds range 50rpm — 4500rpm

Bar Size 50mm

Chuck size 8″

Цена и условия

5 494 178 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 45°

Capability

Max. swing diameter over bed 560mm

Max. swing over cross slide: 350mm

Processing length 500mm

Headstock

Spindle speeds range 50rpm — 4500rpm

Spindle speed steps ranges Stepless-type

Lathe Spindle Nose A2-6

Spindle bore diameter 65mm

Bar Size 50mm

Spindle motor power 11kW / 15kW

Lathe chuck

Chuck size 8″

Clamping type Hydraulic

Through hole Presence

Feeds

X-Axis travel 200mm

X-axis transmission type Ball screw

Z-Axis travel 550mm

Z-axis transmission type Ball screw

Rapid traverse 30000mm/min / 30000mm/min

Carriage

Tool post Lathe turret

Number of stations 8pcs

Tool shank 25mm x 25mm

Tailstock

Tailstock Hydraulic

Max. travel of tailstock quill 100mm

Taper MT5

CNC

Model Fanuc 0i TF (5)

Chip and dust removal systems

Chip removal system Chain type chip conveyor

Chip carrier Presence

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3700kg

Overall length 2800mm

Overall width 1900mm

Overall height 1900mm
