Machine tools and equipment / Bending and forming machinery / Heading machines / Сold heading machines / Сold heading machine TFD6-70
YUHAI

Сold heading machine TFD6-70

Серия: TFD
Workpiece diameter 4mm — 9mm
Max. length of workpiece 70mm
Main slide stroke 100mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Workpiece diameter 4mm — 9mm
Max. length of workpiece 70mm
Production capacity 100pcs/min — 120pcs/min

Processing parameters

Max. cut-off length 110mm

Working area

Main slide stroke 100mm
Main Die 50mm х 120mm
Punch Die (1st) 35mm х 120mm
Punch 2rd 35mm х 120mm
Cut-off die 24mm х 40mm
Cutter 12mm х 35mm х 77mm

Engines and power supply

Total motor power 5.5kW

Overall dimensions and weight

Weight 3280kg
Overall length 2600mm
Overall width 1400mm
Overall height 1600mm
