Machine tools and equipment / Metalworking machine tools / Metal lathes / Swiss-type lathes / Swiss-type CNC lathe SY2-42E(B)
CHIAH CHYUN

Swiss-type CNC lathe SY2-42E(B)

Серия: SY2
Linear axis number 6pcs / X1 / X2 / Y1 / Y2 / Z1 / Z2
Total tools quantity 11pcs / 18pcs / 29pcs
Machining range diameter (spindle/subspindle) 42mm / 42mm
Max. processing length 320mm / Removable Rotary Guide Bush

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Linear axis number 6pcs / X1 / X2 / Y1 / Y2 / Z1 / Z2
Total tools quantity 11pcs / 18pcs / 29pcs
Modification Dual spindles swiss-type lathe
CNC Syntec

Processing parameters

Machining range diameter (spindle/subspindle) 42mm / 42mm
Max. processing length 320mm / Removable Rotary Guide Bush

Main spindle

Spindle drive Belt drive
Spindle bore diameter 42mm
C axis 0.001°
Motor power 7.5kW
Spindle speeds range
4500rpm
6000rpm

Back spindle

Spindle drive Belt drive
Spindle bore diameter 42mm
C axis 0.001°
Motor power 4.4kW
Spindle speeds range
4500rpm
6000rpm

Cross driven tools main spindle

Cross driven tools 6pcs / ER20 / 6000rpm
Motor power 1.5kW

Main spindle O.D. turning tools

Tool seat arrangement Upside tool holder
Tool number 1pcs
Tool Size 20mm x 20mm
tool number 5pcs
tool size 16mm х 16mm

Main spindle end face tools

End-face driven tools 4pcs / ER20 / 6000rpm
End-face fixed tools 5pcs / 25mm
Motor power 0.75kW

Sub-spindle end face tools

End-face driven tools 4pcs / ER20 / 6000rpm
End-face fixed tools 4pcs / 25mm
Motor power 3kW

Linear axes

Rapid traverse 30m/min / 30m/min / 30m/min / 5m/min / 30m/min / 30m/min
Axis drive motor power 1.3kW / 0.85kW / 1.3kW / 0.75kW / 0.85kW / 0.85kW

Other

Water tank capacity 240L
Power of coolant pump motor 0.75kW
Hydraulic Tank Capacity 46L
Motor power of hydraulic station 0.75kW

Overall dimensions and weight

Weight 4805kg
Overall length 3730mm
Overall width 1806mm
Overall height 2155mm

Периферия

Automatic barfeeders

GT 342 3.0
GT 342 3.0
Bar Size : 3mm — 42mm , Magazine capacity : 28pcs \ 10mm

Chip conveyors

Ленточный
Ленточный
Шнековый
Шнековый

Комплектация

Air-conditioner for electrical cabinet
Automatic centralized oil lubrication
Axial drive unit
Количество: 1 pcs
Bar feeder collet
Bar feeder interface
Driven Tool Holder
Количество: 5 pcs
Fixed Tool Holder
Количество: 4 pcs
Front Door Safety System
Guide bush
Guide sleeve collet
High pressure coolant pump
70 bar
Main spindle collet
Oil mist collector
Parts catcher
Parts Ejector
Radial drive unit
Количество: 1 pcs
Status tower light
Sub spindle collet
Tools box
Transformer
Лампа освещения рабочей зоны
