Machine tools and equipment / Metalworking machine tools / Metal lathes / Swiss-type lathes / Swiss-type CNC lathe D266D
JSWAY

Swiss-type CNC lathe D266D

Серия: D
Linear axis number 6pcs / X1 / X2 / Y1 / Y2 / Z1 / Z2
Total tools quantity 16pcs / 16pcs / 32pcs
Modification Dual spindles swiss-type lathe
Machining range diameter (spindle/subspindle) 26mm / 26mm
Max. processing length 220mm / Removable Rotary Guide Bush

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Linear axis number 6pcs / X1 / X2 / Y1 / Y2 / Z1 / Z2
Total tools quantity 16pcs / 16pcs / 32pcs
Modification Dual spindles swiss-type lathe
CNC
Syntec 220TB
Fanuc 0i-TF Plus

Processing parameters

Machining range diameter (spindle/subspindle) 26mm / 26mm
Max. processing length 220mm / Removable Rotary Guide Bush

Main spindle

Spindle drive Direct drive
Spindle speeds range 8000rpm
Spindle bore diameter 28mm
C axis 0.001°
Max. drilling diameter 12mm
Tapping capacity M10
Motor power
8.2kW
5.5kW

Back spindle

Spindle drive Direct drive
Spindle speeds range 8000rpm
Spindle bore diameter 26mm
C axis 0.001°
Max. drilling diameter 10mm
Tapping capacity M8
Motor power
8.2kW
5.5kW

Cross driven tools main spindle

Cross driven tools 5pcs / ER20 / 5500rpm
Max. drilling diameter 12mm
Tapping capacity M10
Motor power 1kW

Main spindle O.D. turning tools

Tool seat arrangement Upside tool holder
Tool number 7pcs
Tool Size 16mm x 16mm

Main spindle end face tools

End-face driven tools 3pcs / ER20
End-face fixed tools 4pcs / ER16

Sub-spindle end face tools

End-face driven tools 8pcs / ER16
End-face fixed tools 5pcs / ER16

Linear axes

Rapid traverse 20m/min / 32m/min / 32m/min / 32m/min / 32m/min / 32m/min
Axis drive motor power 0.75kW / 0.75kW / 1.2kW / 0.75kW / 0.75kW / 0.75kW

Overall dimensions and weight

Weight 2600kg
Overall length 2300mm
Overall width 1250mm
Overall height 1750mm

Периферия

Automatic barfeeders

XT 320 S2 (3.2)
XT 320 S2 (3.2)
Bar Size : 26mm , Max. bar lenght : 3200mm

Chip conveyors

FEDEK HB
FEDEK HB
JSWAY standard chip conveyor
JSWAY standard chip conveyor

Комплектация

Air-conditioner for electrical cabinet
Automatic centralized oil lubrication
Bar feeder collet
Bar feeder interface
Guide bush
Guide sleeve collet
High pressure coolant pump
Hydraulic Unit
Main spindle collet
Oil mist collector
Parts catcher
Status tower light
Sub spindle collet
Tools box
Transformer
Светодиодная лампа освещения рабочей зоны
