Machine tools and equipment / Metalworking machine tools / Metal lathes / Swiss-type lathes / Swiss-type CNC lathe TD365A
JSWAY

Swiss-type CNC lathe TD365A

Серия: TD
Linear axis number 5pcs / X1 / X2 / Y1 / Z1 / Z2
Total tools quantity 18pcs / 5pcs / 23pcs
Machining range diameter (spindle/subspindle) 35mm / 35mm
Max. processing length 220mm / Removable Rotary Guide Bush

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Linear axis number 5pcs / X1 / X2 / Y1 / Z1 / Z2
Total tools quantity 18pcs / 5pcs / 23pcs
Modification Dual spindles swiss-type lathe
CNC
Syntec 220TB
Fanuc 0i-TF Plus

Processing parameters

Machining range diameter (spindle/subspindle) 35mm / 35mm
Max. processing length 220mm / Removable Rotary Guide Bush

Main spindle

Spindle drive Direct drive
Spindle speeds range 6000rpm
Spindle bore diameter 36.5mm
C axis 0.001°
Max. drilling diameter 12mm
Tapping capacity M10
Motor power 11kW

Back spindle

Spindle drive Direct drive
Spindle speeds range 6000rpm
Spindle bore diameter 35mm
C axis 0.001°
Max. drilling diameter 10mm
Tapping capacity M8
Motor power 11kW

Cross driven tools main spindle

Cross driven tools 5pcs / ER20 / 5500rpm
Max. drilling diameter 10mm
Tapping capacity M8
Motor power 1kW

Main spindle O.D. turning tools

Tool seat arrangement Upside tool holder
Tool number 7pcs
Tool Size 16mm x 16mm

Main spindle end face tools

End-face fixed tools 5pcs / ER16

Sub-spindle end face tools

End-face fixed tools 6pcs / ER16

Linear axes

Rapid traverse 20m/min / 32m/min / 32m/min / 32m/min / 32m/min
Axis drive motor power 1.3kW / 0.85kW / 0.85kW / 0.85kW / 0.85kW

Overall dimensions and weight

Weight 3800kg
Overall length 2618mm
Overall width 1497mm
Overall height 1737mm

Периферия

Automatic barfeeders

GT 342 3.0
GT 342 3.0
Bar Size : 3mm — 42mm , Magazine capacity : 28pcs \ 10mm

Chip conveyors

FEDEK HB
FEDEK HB
JSWAY standard chip conveyor
JSWAY standard chip conveyor

Комплектация

Air-conditioner for electrical cabinet
Automatic centralized oil lubrication
Bar feeder collet
Bar feeder interface
Guide bush
Guide sleeve collet
High pressure coolant pump
Hydraulic Unit
Main spindle collet
Oil mist collector
Parts catcher
Status tower light
Sub spindle collet
Tools box
Transformer
Светодиодная лампа освещения рабочей зоны
