Machine tools and equipment / Metalworking machine tools / Metal lathes / Swiss-type lathes / Swiss-type CNC lathe B0126-V
TSUGAMI

Swiss-type CNC lathe B0126-V

Серия: B0
Linear axis number 6pcs / X1 / X2 / Y1 / Y2 / Z1 / Z2
Total tools quantity 21pcs / 4pcs / 25pcs
Modification Dual spindles swiss-type lathe
Machining range diameter (spindle/subspindle) 12mm / 12mm
Max. processing length 210mm / Stationary guide bushing

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Linear axis number 6pcs / X1 / X2 / Y1 / Y2 / Z1 / Z2
Total tools quantity 21pcs / 4pcs / 25pcs
Modification Dual spindles swiss-type lathe
CNC Fanuc 0i-TF Plus

Processing parameters

Machining range diameter (spindle/subspindle) 12mm / 12mm
Max. processing length 210mm / Stationary guide bushing

Main spindle

Spindle drive Direct drive
Spindle cooling Oil cooling
Spindle speeds range 200rpm — 12000rpm
Spindle bore diameter 16mm
C axis 0.001°
Max. drilling diameter 7mm
Tapping capacity M6
Motor power 2.2kW / 3.7kW

Back spindle

Spindle drive Direct drive
Spindle cooling Oil cooling
Spindle speeds range 200rpm — 12000rpm
Spindle bore diameter 23.5mm
C axis 0.001°
Max. drilling diameter 8mm
Tapping capacity M8
Motor power 2.2kW / 3.7kW

Cross driven tools sub spindle

Cross driven tools 2pcs / ER11 / 8000rpm
Max. drilling diameter 6mm
Tapping capacity M5
Motor power 0.75kW

Main spindle O.D. turning tools

Tool seat arrangement Side offset tool holder
Tool number 9pcs
Tool Size 12mm x 12mm x 85mm

Main spindle end face tools

End-face fixed tools 4pcs / 20mm

Sub-spindle end face tools

End-face driven tools 2pcs / ER11
End-face fixed tools 8pcs

Linear axes

X1 Travel 42mm
X2-Axis travel 355mm
Y1 Travel 160mm
Y2-Axis travel 58mm
Z1 Travel 210mm
Z2-Axis travel 200mm
Rapid traverse 24m/min / 36m/min / 32m/min / 15m/min / 32m/min / 36m/min
Axis drive motor power 0.5kW / 0.5kW / 0.5kW / 0.5kW / 0.5kW / 0.5kW

Other

Water tank capacity 210L
Power of coolant pump motor 0.25kW

Overall dimensions and weight

Weight 2000kg
Overall length 2015mm
Overall width 1175mm
Overall height 1730mm

Периферия

Automatic barfeeders

XT 320 S2 (3.2)
XT 320 S2 (3.2)
Bar Size : 26mm , Max. bar lenght : 3200mm

Chip conveyors

FEDEK HB
FEDEK HB

Комплектация

Air reservoir system
Automatic centralized oil lubrication
Automatic cut-off function
Programmatic
Bar feeder collet
Bar feeder interface
Coolant level switch
Front Door Safety System
Guide bush
Stationary guide bushing
Guide bush
Direct-drive rotary guide bushing
Guide bush
Absence
Guide bush
Carrier type rotary guide bushing
Guide sleeve collet
High pressure coolant pump
Live tool of front tool post
4T
M30 automatic power off system
Main spindle and sub spindle C-axis control
Main spindle collet
Oil mist collector
Parts catcher
Parts Ejector
Spindle cone air blow device
Status tower light
Sub spindle collet
Tools box
Work conveyor
Лампа освещения рабочей зоны
