DMTG

Turning center DL-40MH

Серия: DL

Max. swing diameter over bed 900mm

Основная конфигурация

Processing length

1000mm

1500mm

2000mm

3000mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe

Capability

Max. swing diameter over bed 900mm

Processing length

1000mm

1500mm

2000mm

3000mm

Feeds

X-Axis travel 435mm

Rapid traverse 12000mm/min / 16000mm/min

Z-Axis travel

1020mm

1520mm

2020mm

3020mm

Positioning accuracy

0.011mm / 0.018mm / 44'' / 44'

0.011mm / 0.021mm / 44'' / 44'

Repeatability accuracy

0.004mm / 0.007mm / 18''

0.004mm / 0.009mm / 18''

Carriage

Tool post Lathe turret

Tools

Tooling Static tooling

Tools quantity 12pcs

Tool shank 32mm x 25mm

Tailstock

Max. travel of tailstock quill 180mm

Tailstock quill diameter 160mm

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC
