JSWAY

Turning center MYL1000

Серия: MYL

CNC lathe type Slant-bed CNC lathe / 30°

Y-axis Presence

Max. swing over cross slide: 450mm

Processing length 1000mm

Spindle bore diameter 90mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

Y-axis Presence

Capability

Max. swing over cross slide: 450mm

Processing length 1000mm

Main spindle

Lathe Spindle Nose A2-8

Spindle bore diameter 90mm

Bar Size 72mm

Back spindle

Spindle motor power

30kW

26kW

Feeds

X-Axis travel 230mm

X-axis transmission type Ball screw / Ø 32mm

Z-Axis travel 1020mm

Z-axis transmission type Ball screw / Ø 32mm

Y-Axis travel 50mm

Rapid traverse 30000mm/min / 30000mm/min / 30000mm/min

Positioning accuracy 0.005mm / 0.005mm / 0.005mm

Repeatability accuracy 0.005mm / 0.005mm / 0.005mm

Feed motor

Power of feed motors

2.9kW / 2.9kW / 2.9kW

2.5kW / 2.5kW / 2.5kW

Carriage

Tool post Lathe turret

Tools

Tooling Live tooling

Tools quantity 12pcs

Tool holder interface BMT65

Motor power

5.5kW

3.7kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Lubrication system

Lubrication system Full-automatic

Overall dimensions and weight

Weight 6500kg

Overall length 3373mm

Overall width 2324mm

Overall height 2339mm
