XILI

Turret Milling Machine XL6336СL

Серия: XL6

Milling machine variation Universal

Milling Horizontal / Vertical

Working table size 1600mm x 360mm

Max. weight of workpiece 350kg

Milling head swivel angle -45° / 45°

Характеристики

Basic feauturies

Milling machine variation Universal

Milling Horizontal / Vertical

Horizontal worktable

Working table size 1600mm x 360mm

T-slots 3pcs / 18mm / 80mm

Max. weight of workpiece 350kg

Vertical spindle

Spindle speeds range 65rpm — 5440rpm

Spindle speed steps ranges 16pcs

Spindle taper ISO40

Milling head swivel angle -45° / 45°

Travel of spindle quill 127mm

Distance between spindle end and surface of worktable 200mm — 650mm

Spindle motor power 5.5kW

Horizontal spindle

Spindle speeds range 60rpm — 1800rpm

Spindle speed steps ranges 12pcs

Spindle taper ISO50

Distance from horizontal spindle axist to surface of working table 20mm — 470mm

Distance between spindle axis and ram 245mm

Ram travel 550mm

Spindle motor power 5.5kW

Feeds

Manual feed travels 1300mm / 320mm / 450mm

Min. speed of traverse feeds 30mm/min / 20mm/min / 15mm/min

Max. speed of traverse feeds 750mm/min / 500mm/min / 375mm/min

Rapid traverse 1200mm/min / 800mm/min / 600mm/min

Torque of axis-drive motors 15N⋅m

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 2850kg

Overall length 2520mm

Overall width 2100mm

Overall height 2500mm

Периферия

Dividing heads

XL6336CL

Tilting Rotary Tables

XL6336 table

Digital Readout Unit (DRO)

DRO SINO SDS6-3V

Rotary tables

Rotary table TSL250

Table diameter : 250mm

Machine vise

QH160

Width of vice jaw : 160mm , Height of vice jaw : 50mm , Max. open distance of vice jaw : 125mm
