Характеристики
Basic feauturies
Milling machine variationRam-type milling machine
MillingHorizontal / Vertical
Capability
End milling dimension40mm
Milling width250mm
Horizontal worktable
Working table size1650mm x 360mm
T-slots3pcs / 14mm / 95mm
Max. weight of workpiece350kg
Swivel angle-35° / 35°
Vertical spindle
Spindle speeds range60rpm — 1750rpm
Spindle speed steps ranges12pcs
Spindle taperISO50
Milling head swivel angle-360° / 360°
Distance between spindle end and surface of worktable170mm — 590mm
Spindle motor power4kW
Horizontal spindle
Spindle speeds range58rpm — 1800rpm
Spindle speed steps ranges12pcs
Spindle taperISO50
Distance from horizontal spindle axist to surface of working table420mm
Distance between spindle axis and ram 175mm
Ram travel500mm
Spindle motor power5.5kW
Feeds
Manual feed travels1300mm / 300mm / 420mm
Mechanical feed travels1300mm / 300mm / 420mm
Min. speed of traverse feeds25mm/min / 25mm/min / 8mm/min
Max. speed of traverse feeds800mm/min / 800mm/min / 267mm/min
