Machine tools and equipment / Metalworking machine tools / Metal lathes / Vertical CNC lathes / Vertical CNC Lathe T6-85Q
SMTCL

Vertical CNC Lathe T6-85Q

Серия: T
Max. swing diameter over bed 1000mm
Turning diameter 850mm
Processing length 850mm

Цена и условия

Цена по запросу

Характеристики

Capability

Max. swing diameter over bed 1000mm
Turning diameter 850mm
Processing length 850mm

Spindle

Spindle speeds range 1100rpm
Lathe Spindle Nose A2-11
Spindle motor power 22kW / 30kW
Spindle torque 1910N⋅m

Lathe chuck

Chuck size 21″

Feeds

X-Axis travel 480mm
Z-Axis travel 850mm
Rapid traverse 16000mm/min / 16000mm/min
Positioning accuracy 0.012mm / 0.015mm
Repeatability accuracy 0.008mm / 0.008mm

Carriage

Tool post Lathe turret / Vertical
Number of stations 8pcs

CNC

CNC model Fanuc

Chip and dust removal systems

Chip removal system Chain type chip conveyor

Other

Accuracy class index IT-7

Overall dimensions and weight

Weight 10500kg
Overall length 2632mm
Overall width 2110mm
Overall height 3562mm
