SMTCL

Vertical CNC machining center VMC850Q

Серия: VMC(Q)

Working table size 1000mm x 500mm

Max. weight of workpiece 600kg

Spindle speeds range 12000rpm

Spindle motor power 7.5kW / 11kW

Feed travels 850mm / 500mm / 540mm

Цена и условия

5 578 714 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Working table

Working table size 1000mm x 500mm

T-slots 5pcs / 18mm

Max. weight of workpiece 600kg

Spindle

Spindle speeds range 12000rpm

Spindle drive Belt drive

Spindle taper BT40

Spindle motor power 7.5kW / 11kW

Spindle torque 35.8N⋅m / 70N⋅m

Distance from axis of vertical spindle to bed guideway 640mm

Distance from vertical spindle nose to surface of working table 120mm / 660mm

Automatic tool changer (ATC)

Tool changing type With robotic arm

Tool magazine capacity 24pcs

Max. tool diameter 150mm / 80mm

Max. tool lenght 300mm

Max. tool weight 7kg

Tool сhanging time (Tool-to-Tool) 2.5sec.

Feeds

Feed travels 850mm / 500mm / 540mm

Min. speed of traverse feeds 1mm/min / 1mm/min / 1mm/min

Max. speed of traverse feeds 20000mm/min / 20000mm/min / 20000mm/min

Rapid traverse 48000mm/min / 48000mm/min / 48000mm/min

Power of feed motors 1.8kW / 1.8kW / 3kW

Torque of axis-drive motors 11N⋅m / 11N⋅m / 20N⋅m

X-axis transmission type Ball screw

Y-axis transmission type Ball screw

Z-axis transmission type Ball screw

CNC

Model Fanuc 0i MF Plus

Engines and power supply

Total motor power 18kW

Voltage 380V / 50Hz

Other

Lubrication system Full-automatic

Electrical cabinet With heat exchanger

Splash guard cover Full splash guard

Overall dimensions and weight

Weight 5100kg

Overall length 2400mm

Overall width 2975mm

Overall height 2840mm
