Machine tools and equipment / Metalworking machine tools / Electrical discharge machines (EDM) / Wire-cut electrical discharge (WEDM) machines / Wire cut EDM A530
WNJ

Wire cut EDM A530

Серия: A
Max. weight of workpiece 300kg
X/Y-Axis travel 500mm / 300mm
Z-Axis travel 300mm

Цена и условия

2 084 840 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Machine unit

Max. weight of workpiece 300kg
Max. taper angle 6° / 100mm
Wire Molybdenum
Wire diameter 0.15mm — 0.2mm

CNC

Software Windows based
Controlled axis X-axis / Y-axis / Z-axis / U-axis / V-axis
EDM control system Close loop software servo system

Feeds

X/Y-Axis travel 500mm / 300mm
Z-Axis travel 300mm

Accuracy

Machining Accuracy 0.005mm
Best surface roughness 0.8μm/Ra

Pulse generator

Power input 2kW

Dielectric fluid unit

Tank capacity 150L

Other

X-axis drive Servomotor
Y-axis drive Servomotor
Z-axis drive Servomotor
U-axis drive Servomotor
V-axis drive Servomotor

Overall dimensions and weight

Weight 1800kg
Overall length 1800mm
Overall width 1350mm
Overall height 2000mm
