Machine tools and equipment / Metalworking machine tools / Electrical discharge machines (EDM) / Wire-cut electrical discharge (WEDM) machines / Wire cut EDM S1080
WNJ

Wire cut EDM S1080

Серия: S
Max. weight of workpiece 1200kg
X/Y-Axis travel 1000mm / 800mm
Z-Axis travel 400mm
U-Axle travel 30mm
V-Axle travel 30mm

Цена и условия

Цена по запросу

Характеристики

Machine unit

Max. weight of workpiece 1200kg
Max. taper angle 6° / 100mm
Wire Molybdenum
Wire diameter 0.15mm — 0.2mm

CNC

Software Windows based
Controlled axis X-axis / Y-axis / U-axis / V-axis
Setting limits 0.001mm
EDM control system Semi-close loop software servo system

Feeds

X/Y-Axis travel 1000mm / 800mm
Z-Axis travel 400mm
U-Axle travel 30mm
V-Axle travel 30mm

Accuracy

Machining Accuracy 0.005mm
Best surface roughness 1μm/Ra

Pulse generator

Operating current 9A
Power input 2kW

Dielectric fluid unit

Tank capacity 150L

Other

Z-axis drive Servomotor
U-axis drive Servomotor
V-axis drive Servomotor

Overall dimensions and weight

Weight 5500kg
Overall length 2250mm
Overall width 2000mm
Overall height 2100mm
