Machine tools and equipment / Metalworking machine tools / CNC machining centers / 5-Axis CNC Machining Center / 5-Axis CNC Machining Center LU-400
LITZ

5-Axis CNC Machining Center LU-400

Серия: LU
Working table size 450mm
Max. weight of workpiece 200kg
Feed travels 400mm / 350mm / 350mm
B Axis Tilting Range -50° ~ 110°
Rotation range of C-axis 360°

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 450mm
T-slots 8pcs / 14mm
Max. weight of workpiece 200kg

Feeds

Feed travels 400mm / 350mm / 350mm
B Axis Tilting Range -50° ~ 110°
Rotation range of C-axis 360°
Max. speed of traverse feeds 20000mm/min / 20000mm/min / 20000mm/min
Max. rotation speed of the B-axis 25rpm
Max. rotation speed of axis C 25rpm
Rapid traverse 48000mm/min / 48000mm/min / 48000mm/min
Power of feed motors 4.5kW / 2.7kW / 4.5kW / 7kW / 2.7kW

Spindle

Spindle drive Direct drive
Spindle taper ISO40
Spindle cooling Oil cooling
Distance from vertical spindle nose to surface of working table 150mm / 500mm
Spindle motor power 5.5kW / 7.5kW
Spindle speeds range
12000rpm
15000rpm

Automatic tool changer (ATC)

Taper size HSK-A63
Max. tool diameter 127mm / 75mm
Max. tool lenght 250mm
Tool magazine capacity
30pcs
48pcs

CNC

CNC
Fanuc 0i-MF
Heidenhain TNC-620
Heidenhain TNC-640
SINUMERIK 840D sl
Number of simultaneously controlled axes
4pcs + 1pcs
4pcs + 1pcs
5pcs
5pcs

Cutting fluid

Water tank capacity 220L

Engines and power supply

Total power input 20kVA
Compressed Air Supply 1600l/min

Overall dimensions and weight

Weight 6000kg
Overall length 2080mm
Overall width 2400mm
Overall height 2720mm

Периферия

Chip conveyors

Chain Chip conveyor DMTG
Chain Chip conveyor DMTG

Workpiece measurement system

TC60
TC60

Tool measuring system

NT-A3
NT-A3

Комплектация

3-axes linear roller guideway
3-axes linear scale
Air blow gun
Air-conditioner for electrical cabinet
Air Outlet for Fixture
Anti-collision function
Center calibration function
CE specifications
Coolant cooling system
Coolant gun
Coolant splash ring for spindle
Disc oil and coolant separator
Encoders on the B/C axes
Front Door Safety System
Full protection cover
Heater exchanger for electrical cabinet
High pressure coolant pump
M30 automatic power off system
Manual Pulse Generator (MPG)
Oil mist collector
Rotating viewing window
Spindle dust-proof air-sealing system
Spindle external programmable air blow system
Status tower light
Thermal compensation function
Tools box
Top enclosure
Transformer
Wash down device
Worktable Tailstock support
Z-axis brake motor system
Автоматическая смазка направляющих
Лампа освещения рабочей зоны
Х/Y/Z axis bellows
