Machine tools and equipment / Metalworking machine tools / CNC machining centers / 5-Axis CNC Machining Center / 5-Axis CNC Machining Center LU-620
LITZ

5-Axis CNC Machining Center LU-620

Серия: LU
Working table size 650mm
Max. weight of workpiece 500kg
Feed travels 620mm / 520mm / 460mm
B Axis Tilting Range -50° ~ 110°
Rotation range of C-axis 360°

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 650mm
T-slots 8pcs / 18mm
Max. weight of workpiece 500kg

Feeds

Feed travels 620mm / 520mm / 460mm
B Axis Tilting Range -50° ~ 110°
Rotation range of C-axis 360°
Max. speed of traverse feeds 20000mm/min / 20000mm/min / 20000mm/min
Max. rotation speed of the B-axis 25rpm
Max. rotation speed of axis C 25rpm
Rapid traverse 36000mm/min / 36000mm/min / 36000mm/min
Power of feed motors 6.5kW / 4.5kW / 6.5kW / 8.6kW / 4.5kW

Spindle

Spindle taper ISO40
Spindle motor power 18kW / 21kW
Spindle speeds range
12000rpm
15000rpm

Automatic tool changer (ATC)

Taper size HSK-A63
Max. tool diameter 127mm / 75mm
Max. tool lenght 250mm
Tool magazine capacity
32pcs
48pcs

CNC

CNC model
HEIDENHAIN TNC-640
SIEMENS 840 Dsl
Number of simultaneously controlled axes
5pcs
5pcs

Cutting fluid

Water tank capacity 240L

Engines and power supply

Total power input 25kVA
Compressed Air Supply 1600l/min

Chip and dust removal systems

Chip removal system Chain type chip conveyor
Chip carrier Presence

Other

Spindle cone air blow device Presence
Lubrication system Full-automatic
Electrical cabinet With heat exchanger
Work area lighting Presence
MPG Presence
Splash guard cover Full splash guard

Overall dimensions and weight

Weight 8800kg
Overall length 2260mm
Overall width 2590mm
Overall height 3060mm
