PowerJet

All-Electric Injection Molding Machine JT120E

Серия: JT

Machine drive All-electric

Clamping force 1200kN

Ejector stroke 100mm

Основная конфигурация

Model

B288G

Screw diameter

28mm

Theoretical shot volume

89.24cm³

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Machine drive All-electric

Injection Unit

Model

B288G

Screw diameter

28mm

Screw ratio

20.5L/D

Max. rotational speed

400rpm

Theoretical shot volume

89.24cm³

Injection pressure

324MPa

Injection weight

79.42g

Injection speed

9.4g/s

Clamping unit

Clamping force 1200kN

Clamping stroke 360mm

Thickness of mould 150mm / 480mm

Space between tie bars 470mm x 470mm

Ejector stroke 100mm

Ejector force 29.4kN

Other

Heating power

4kW

Overall dimensions and weight

Weight 4800kg

Overall length 4690mm

Overall width 1460mm

Overall height 195mm
