PowerJet

All-Electric Injection Molding Machine JT90E

Серия: JT

Machine drive All-electric

Clamping force 900kN

Ejector stroke 100mm

Основная конфигурация

Model

B188K

Screw diameter

28mm

Theoretical shot volume

73.85cm³

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Machine drive All-electric

Injection Unit

Model

B188K

Screw diameter

28mm

Screw ratio

20.5L/D

Max. rotational speed

400rpm

Theoretical shot volume

73.85cm³

Injection pressure

246.1MPa

Injection weight

65.73g

Injection speed

9.4g/s

Clamping unit

Clamping force 900kN

Clamping stroke 320mm

Thickness of mould 150mm / 410mm

Space between tie bars 420mm x 420mm

Ejector stroke 100mm

Ejector force 19.6kN

Other

Heating power

4kW

Overall dimensions and weight

Weight 3800kg

Overall length 4270mm

Overall width 1350mm

Overall height 1830mm
