YORNEW

Bench CNC lathe CK210

Серия: CK

Modification CNC lathe

Max. swing diameter over bed 210mm

Max. swing over cross slide: 80mm

Distance between centers 290mm

Spindle speeds range 300rpm — 1750rpm

Spindle motor power 1.1kW

Model Siemens 808D

Цена и условия

1 319 372 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Modification CNC lathe

Capability

Max. swing diameter over bed 210mm

Max. swing over cross slide: 80mm

Distance between centers 290mm

Headstock

Spindle speeds range 300rpm — 1750rpm

Spindle taper MT4

Spindle bore diameter 26mm

Spindle motor power 1.1kW

Type of electric motor Servomotor

Spindle cooling Water cooling

Feeds

Power of feed motors 0.4kW

X-Axis travel 90mm

Z-Axis travel 300mm

Max. speed of traverse feeds 2000mm/min / 2000mm/min

Rapid traverse 8000mm/min / 8000mm/min

Carriage

Number of stations 4pcs

Tool shank 12mm x 12mm

Lathe chuck

Chuck size 100mm

Clamping type Mechanical

Chuck 3-jaw chuck

Tailstock

Tailstock quill diameter 26mm

Taper MT2

Indication and control

Indication and control CNC

Model Siemens 808D

Accuracy

Positioning accuracy 0.003mm / 0.003mm

Repeatability accuracy 0.002mm / 0.002mm

Engines and power supply

Voltage 220V / 50Hz / AC

Overall dimensions and weight

Weight 220kg

Overall length 1170mm

Overall width 750mm

Overall height 750mm
