Triple Tech

CNC Die-sink EDM machine CNC-B45

Серия: CNC

Working table size 700mm x 400mm

X/Y-Axis travel 450mm / 350mm

Ram vertical travel 300mm

Max. weight of workpiece 450kg

Цена и условия

4 059 800 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Machine unit

Working table size 700mm x 400mm

Work tank inner size 1320mm x 730mm x 390mm

X/Y-Axis travel 450mm / 350mm

Ram vertical travel 300mm

Max. workpiece dimensions 800mm x 600mm x 260mm

Max. weight of workpiece 450kg

Distance between table surface and electrode plate 145mm – 445mm

Max. electrode weight 120kg

Dielectric fluid unit

Overall dimensions 1500mm x 700mm x 430mm

Pulse generator

Operating current 50A

Total power input 9kVA

Max.material removal rate 400mm³/min

Electrode wear rate 0.1%

Best surface roughness 0.1μm/Ra

Overall dimensions 1100mm x 520mm x 1850mm

Weight 400kg

CNC

EDM system CNC

Controlled axis X-axis / Y-axis / Z-axis

Setting limits 0.4mm

Engines and power supply

Voltage 380V / 50Hz

Other

Y-axis drive Servomotor

X-axis drive Servomotor

Z-axis drive Servomotor

Overall dimensions and weight

Weight 2200kg

Overall length 2400mm

Overall width 2200mm

Overall height 2300mm
