EN | JOTING

CNC forming machine QDM-CNC40T

Серия: QDM

Wire diameter 2mm — 8mm

Metal strip processing size 3mm x 60mm

Production capacity 150pcs/min

Цена и условия

3 176 135 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Spring-forming machine variation Cam machine

CNC

CNC language Chinese / English

Processing parameters

Wire diameter 2mm — 8mm

Length of WIRE Feeding No limitation

Wire feed value 0.05mm

Thickness of StripWire 0.5mm — 3mm

Metal strip processing size 3mm x 60mm

Hardness of Wire 100 (CARBON)

Punch stroke 70mm

Capability

Production capacity 150pcs/min

Punch processing ability 40tn

The sliding seat processing ability 6tn

Engines and power supply

Voltage 380V / 50Hz / Three phase

Wire feed axis motor 4.5kW

Press motor 15kW

Cam axis motor 3.5kW

Overall dimensions and weight

Weight 6500kg

Overall length 3200mm

Overall width 2100mm

Overall height 2300mm
