STS

CNC Horizontal Lathe CT46

Серия: CT

Max. swing diameter over bed 380mm

Spindle speeds range 5000rpm

Spindle motor power 11kW / 18.5kW

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 45°

Capability

Max. swing diameter over bed 380mm

Max Cutting Diameter 380mm

Max. swing over cross slide: 320mm

Processing length 300mm — 500mm

Headstock

Spindle speeds range 5000rpm

Lathe Spindle Nose A2-5

Spindle bore diameter 56mm

Bar Size 45mm

Spindle torque 47N⋅m

Spindle motor power 11kW / 18.5kW

Model

SYNTEC 22TA

FANUC 0i-TF PLUS

Siemens 828D

Lathe chuck

Chuck size 6″

Clamping type Hydraulic

Feeds

X-Axis travel 210mm

Z-Axis travel 380mm

Rapid traverse 20000mm/min / 20000mm/min

Positioning accuracy 0.01mm / 0.01mm

Repeatability accuracy 0.002mm / 0.002mm

Power of feed motors 1.3kW / 1.3kW / 3.24kW

Carriage

Tool post Lathe turret

Number of stations 12pcs

Engines and power supply

Total motor power 10kW / 2pcs

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3000kg

Overall length 2670mm

Overall width 1664mm

Overall height 1875mm
