STS

CNC Horizontal Lathe CT52

Серия: CT

Max. swing diameter over bed 380mm

Processing length 300mm — 500mm

Spindle speeds range 4000rpm

Chuck size 8″

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 45°

Capability

Max. swing diameter over bed 380mm

Max Cutting Diameter 380mm

Max. swing over cross slide: 320mm

Processing length 300mm — 500mm

Headstock

Spindle speeds range 4000rpm

Lathe Spindle Nose A2-6

Spindle bore diameter 62mm

Bar Size 51mm

Spindle torque 71N⋅m / 90N⋅m

Spindle motor power 15kW / 22kW

Model

SYNTEC 22TA

FANUC 0i-TF PLUS

Siemens 828D

Lathe chuck

Chuck size 8″

Clamping type Hydraulic

Feeds

X-Axis travel 210mm

Z-Axis travel 500mm

Rapid traverse 20000mm/min / 20000mm/min

Positioning accuracy 0.01mm / 0.01mm

Repeatability accuracy 0.002mm / 0.002mm

Power of feed motors 1.3kW / 1.3kW / 3.24kW

Carriage

Tool post Lathe turret

Number of stations 12pcs

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3100kg

Overall length 2670mm

Overall width 1664mm

Overall height 1875mm
