Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC Turning Centers / CNC Turn Mill Lathe MJS1000
JSWAY

CNC Turn Mill Lathe MJS1000

Серия: MJS
CNC lathe type Slant-bed CNC lathe / 30°
Max. swing diameter over bed 615mm
Max. swing over cross slide: 400mm
Processing length 1000mm

Основная конфигурация

CNC
Fanuc 0i-TF Plus
Syntec 220TB
Spindle speeds range
1500rpm
4000rpm
5000rpm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°
Y-axis Presence
C axis Presence

CNC

CNC
Fanuc 0i-TF Plus
Syntec 220TB

Capability

Max. swing diameter over bed 615mm
Max. swing over cross slide: 400mm
Processing length 1000mm

Main spindle

Spindle bore diameter 90mm
Bar Size 72mm
Spindle speeds range
1500rpm
4000rpm
5000rpm
Lathe Spindle Nose
A2-8
A2-6
A2-4
Spindle motor power
26kW
18.5kW
7.9kW
Lathe chuck
-
254mm / Hydraulic / 3-jaw chuck
203mm / Hydraulic / 3-jaw chuck
Collet chuck / CL-80
Collet chuck / CL-60

Back spindle

Bar Size 51mm
Spindle speeds range
2000rpm
4500rpm
5000rpm
Spindle motor power
15kW
11kW
7.9kW
Lathe chuck
-
203mm / Hydraulic / 3-jaw chuck
152.4mm / Hydraulic / 3-jaw chuck
Collet chuck / CL-52
Collet chuck / CL-42

Feeds

X-Axis travel 210mm
X-axis transmission type Ball screw
Z-Axis travel 1020mm
Z-axis transmission type Ball screw
Y-Axis travel 50mm
Rapid traverse 24000mm/min / 24000mm/min / 30000mm/min
Positioning accuracy 0.005mm / 0.005mm / 0.005mm
Repeatability accuracy 0.005mm / 0.005mm / 0.005mm

Feed motor

Power of feed motors 2.5kW / 2.5kW / 2.5kW

Carriage

Tool post Lathe turret

Tools

Tooling Live tooling / Static tooling
Tools quantity 12pcs / 7pcs / 12pcs
Tool holder interface BMT65

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Lubrication system

Lubrication system Full-automatic
Required oil ISO VG68

Overall dimensions and weight

Weight 6200kg
Overall length 3709mm
Overall width 2325mm
Overall height 2340mm

Периферия

Chip conveyors

JSWAY standard chip conveyor
JSWAY standard chip conveyor
Fedek Turbo HF
Fedek Turbo HF

Комплектация

Air-conditioner for electrical cabinet
Boring tool holder
Количество: 1 pcs
Coolant cooling system
End face tool holder
Количество: 1 pcs
External turning tool holder
Количество: 1 pcs
High pressure coolant pump
20 Bar
Oil mist collector
Powered tool holder (±0°)
Количество: 1 pcs
Powered tool holder (±90°)
Количество: 1 pcs
Status tower light
Tricolor
Tools box
Transformer
Количество: 1 pcs
380V
Wash down device
Светодиодная лампа освещения рабочей зоны
