JSWAY

CNC Turn Mill Lathe MJS500

Серия: MJS

CNC lathe type Slant-bed CNC lathe / 30°

Max. swing diameter over bed 450mm

Processing length 500mm

Spindle motor power 15kW

Цена и условия

11 758 228 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

Y-axis Presence

C axis Presence

Capability

Max. swing diameter over bed 450mm

Processing length 500mm

Main spindle

Spindle drive Direct drive

Spindle speeds range 4000rpm

Lathe Spindle Nose A2-6

Spindle bore diameter 62mm

Bar Size 52mm

Spindle motor power 15kW

Back spindle

Spindle speeds range 4500rpm

Lathe Spindle Nose А2-5

Bar Size 45mm

Spindle motor power 11kW

Feeds

X-Axis travel 200mm

X-axis transmission type Ball screw

Z-Axis travel 520mm

Z-axis transmission type Ball screw

Y-Axis travel 50mm

Rapid traverse 24000mm/min / 24000mm/min / 30000mm/min

Positioning accuracy 0.005mm / 0.005mm / 0.005mm

Repeatability accuracy 0.005mm / 0.005mm / 0.005mm

Feed motor

Power of feed motors 1.8kW / 1.8kW / 1.8kW

Carriage

Tool post Lathe turret

Tools

Tooling Live tooling

Tools quantity 12pcs

Tool holder interface BMT65

Tool shank 25mm x 25mm

Tool shank diameter 32mm

Motor power 2.7kW

Live tooling speed 4000rpm

Max. drilling diameter 30mm

Tapping capacity M20

Milling capacity 50mm

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Lubrication system

Lubrication system Full-automatic

Overall dimensions and weight

Weight 5500kg

Overall length 2500mm

Overall width 1948mm

Overall height 1950mm
