Machine tools and equipment / Metalworking machine tools / Metal lathes / Horizontal CNC Lathes / Horizontal CNC Lathe T 5.1-100Q
SMTCL

Horizontal CNC Lathe T 5.1-100Q

Серия: T
CNC lathe type Slant-bed CNC lathe
Max. swing diameter over bed 420mm
Max. swing over cross slide: 160mm
Processing length 160mm

Цена и условия

4 614 074 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe

Capability

Max. swing diameter over bed 420mm
Max. swing over cross slide: 160mm
Processing length 160mm
Bed slant angle 45°

Headstock

Spindle speeds range 5000rpm
Lathe Spindle Nose A2-5
Spindle bore diameter 62mm
Spindle torque 35N⋅m / 70N⋅m
Spindle motor power 7.5kW / 11kW

Lathe chuck

Chuck size 152mm

Feeds

X-Axis travel 145mm
Z-Axis travel 205mm
Rapid traverse 30000mm/min / 30000mm/min

Carriage

Tool post Horizontal
Number of stations 8pcs
Turning diameter 56mm
Indexing time 1.6sec.

CNC

Model FANUC Oi-TF plus(5)

Overall dimensions and weight

Weight 2600kg
Overall length 1750mm
Overall width 1650mm
Overall height 1650mm

Периферия

Lathe toolposts

T 5.2 toolpost 8 pcs
T 5.2 toolpost 8 pcs
T 5.2 toolpost 12 pcs
T 5.2 toolpost 12 pcs
