Machine tools and equipment / Metalworking machine tools / Metal lathes / Horizontal CNC Lathes / Horizontal CNC Lathe T 5.2-1000Q
SMTCL

Horizontal CNC Lathe T 5.2-1000Q

Серия: T
CNC lathe type Slant-bed CNC lathe
Max. swing diameter over bed 560mm
Max. swing over cross slide: 350mm
Processing length 1000mm

Цена и условия

6 335 454 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe

Capability

Max. swing diameter over bed 560mm
Max Cutting Diameter 360mm
Max. swing over cross slide: 350mm
Processing length 1000mm
Bed slant angle 45°

Headstock

Spindle speeds range 4500rpm
Lathe Spindle Nose A2-6
Spindle bore diameter 65mm
Bar Size 50mm
Spindle Bearing Inner Diameter 100mm
Spindle torque 136N⋅m / 245N⋅m
Spindle motor power 11kW / 15kW

Lathe chuck

Chuck size 8″

Feeds

X-Axis travel 200mm
X-axis transmission type Ball screw / Ø 32mm
Z-Axis travel 1050mm
Z-axis transmission type Ball screw / Ø 32mm
Rapid traverse 30000mm/min / 30000mm/min
Positioning accuracy 0.008mm / 0.010mm
Repeatability accuracy 0.004mm / 0.005mm
Power of feed motors 1.8kW / 1.8kW

Carriage

Tool post Horizontal
Indexing time 1.6sec.
Tool shank 25mm x 25mm

Tailstock

Tailstock Electric
Tailstock stroke 950mm
Taper MT5

CNC

Model FANUC 0i-TF Plus (5)

Chip and dust removal systems

Chip removal system Belt conveyor for chip removal
Chip carrier Presence

Other

Accuracy class index IT6
Best surface roughness 1.25μm/Ra
Oil tank capacity 3L
Water tank capacity 200L
Hydraulic Tank Capacity 20L

Overall dimensions and weight

Weight 4750kg
Overall length 3620mm
Overall width 1890mm
Overall height 1900mm

Периферия

Lathe toolposts

T 5.2 toolpost 8 pcs
T 5.2 toolpost 8 pcs
T 5.2 toolpost 12 pcs
T 5.2 toolpost 12 pcs
