Slant Bed CNC Gang Tool Lathe MDW-08Y (MICK), China | Low price

Slant Bed CNC Gang Tool Lathe MDW-08Y

Серия: MDW

Y-axis Presence

Max. swing diameter over bed 460mm

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

Y-axis Presence

Capability

Max. swing diameter over bed 460mm

Main spindle

Spindle speeds range

3500rpm

3000rpm

Spindle bore diameter

52mm

65mm

Feeds

X-Axis travel 460mm

Z-Axis travel 630mm

Y-Axis travel 90mm

Max. speed of traverse feeds 30000mm/min / 10000mm/min / 30000mm/min

Positioning accuracy 0.0025mm / 0.0025mm / 0.0025mm

Feed motor

Power of feed motors 2.4kW / 1.7kW / 2.4kW

Tools

Tool shank 20mm x 20mm

Tool shank diameter 25mm

Cutting fluid

Tank capacity 100L

Power of coolant pump motor 0.18kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Lubrication system

Lubricatingoil pump power 0.04kW

Hydraulic system

Motor power of hydraulic station 1.5kW

Hydraulic Tank Capacity 20L

Overall dimensions and weight

Weight 3500kg

Overall length 3000mm

Overall width 1890mm

Overall height 2205mm
