MICK

Slant Bed CNC Gang Tool Lathe MXC-06Y

Серия: MXC

CNC lathe type Slant-bed CNC lathe / 30°

Y-axis Presence

Max. swing diameter over bed 400mm

Spindle speeds range 4000rpm

Spindle bore diameter 46mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

Y-axis Presence

Capability

Max. swing diameter over bed 400mm

Main spindle

Spindle speeds range 4000rpm

Spindle bore diameter 46mm

Spindle motor power 7.5kW

Feeds

X-Axis travel 900mm

Z-Axis travel 300mm

Y-Axis travel 70mm

Max. speed of traverse feeds 24000mm/min / 10000mm/min / 24000mm/min

Positioning accuracy 0.0025mm / 0.0025mm / 0.0025mm

Feed motor

Power of feed motors 1.8kW / 1.8kW / 1.8kW

Tools

Tools quantity 15pcs

Tool shank 20mm x 20mm

Live tooling speed 5000rpm

Cutting fluid

Tank capacity 60L

Power of coolant pump motor 0.37kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Lubrication system

Lubricatingoil pump power 0.75kW

Hydraulic system

Motor power of hydraulic station 0.75kW

Hydraulic Tank Capacity 20L

Overall dimensions and weight

Weight 2950kg

Overall length 2340mm

Overall width 1940mm

Overall height 2090mm
