Machine tools and equipment / Metalworking machine tools / Metal lathes / Horizontal CNC Lathes / Slant Bed CNC Gang Tool Lathe MXC-52L
MICK

Slant Bed CNC Gang Tool Lathe MXC-52L

Серия: MXC
CNC lathe type Slant-bed CNC lathe / 45°
Max. swing diameter over bed 400mm
Spindle speeds range 3500rpm
Spindle bore diameter 52mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 45°

Capability

Max. swing diameter over bed 400mm

Headstock

Spindle speeds range 3500rpm
Spindle bore diameter 52mm
Spindle motor power 7.5kW

Feeds

X-Axis travel 920mm
Z-Axis travel 330mm
Max. speed of traverse feeds 30000mm/min / 30000mm/min
Positioning accuracy 0.0025mm / 0.0025mm
Power of feed motors 1.3kW / 1.3kW

Carriage

Number of stations 12pcs
Tool Size 20mm
Tool shank 20mm x 20mm

Cutting fluid

Pump motor power 0.37kW

Other

Oil tank capacity 2L
Water tank capacity 60L
Hydraulic Tank Capacity 20L

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 2600kg
Overall length 2200mm
Overall width 1650mm
Overall height 1890mm
