Machine tools and equipment / Metalworking machine tools / Metal lathes / Swiss-type lathes / Swiss-type CNC lathe MA20-5II
Jianke

Swiss-type CNC lathe MA20-5II

Серия: MA
Linear axis number 5pcs / X1 / X2 / Y1 / Z1 / Z2
Total tools quantity 14pcs / 4pcs / 18pcs
Machining range diameter (spindle/subspindle) 20mm / 20mm
Max. processing length 200mm / Removable Rotary Guide Bush

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Linear axis number 5pcs / X1 / X2 / Y1 / Z1 / Z2
Total tools quantity 14pcs / 4pcs / 18pcs
Modification Dual spindles swiss-type lathe
CNC
Syntec 220TB
Fanuc 0i-TF

Processing parameters

Machining range diameter (spindle/subspindle) 20mm / 20mm
Max. processing length 200mm / Removable Rotary Guide Bush

Main spindle

Spindle cooling Oil cooling
Spindle speeds range 10000rpm
Spindle bore diameter 26mm
C axis 0.001°
Max. drilling diameter 10mm
Tapping capacity M8
Motor power 2.5kW / 3.7kW

Back spindle

Spindle cooling Oil cooling
Spindle speeds range 10000rpm
Spindle bore diameter 26mm
C axis 0.001°
Max. drilling diameter 8mm
Tapping capacity M6
Motor power 2.5kW / 3.7kW

Cross driven tools main spindle

Cross driven tools 2pcs / ER11 / 10000rpm
Cross driven tools 2pcs / ER16 / 6000rpm
Max. drilling diameter 8mm
Tapping capacity M6
Motor power 1kW

Main spindle O.D. turning tools

Tool seat arrangement Upside tool holder
Tool number 1pcs
Tool Size 10mm x 10mm
tool number 5pcs
tool size 12mm х 12mm

Main spindle end face tools

End-face fixed tools 4pcs / ER11 / ER16

Sub-spindle end face tools

End-face fixed tools 4pcs / ER11 / ER16

Linear axes

Rapid traverse 24m/min / 32m/min / 32m/min / 32m/min / 32m/min
Axis drive motor power 1kW

Other

Water tank capacity 250L

Overall dimensions and weight

Weight 3050kg
Overall length 2400mm
Overall width 1400mm
Overall height 1700mm

Периферия

Chip conveyors

FEDEK HB
FEDEK HB

Automatic barfeeders

CTG 26 3.0
CTG 26 3.0
Bar Size : 5mm — 26mm , Max. bar lenght : 3100mm , Magazine capacity : 22pcs \ 10mm
XT 320 S2 (3.2)
XT 320 S2 (3.2)
Bar Size : 26mm , Max. bar lenght : 3200mm

Комплектация

Automatic centralized oil lubrication
Bar feeder collet
Bar feeder interface
End face tool holder
Количество: 1 pcs
Sub spindle
End face tool holder
Количество: 1 pcs
Main spindle
External turning tool holder
Количество: 1 pcs
Guide bush
Guide sleeve collet
High pressure coolant pump
Main spindle collet
Oil mist collector
Parts catcher
Parts Ejector
Radial drive unit
Количество: 1 pcs
Status tower light
Sub spindle collet
Tools box
Transformer
Лампа освещения рабочей зоны
