TORNOS

Swiss-type CNC lathe GT 26

Серия: GT

Linear axis number 6pcs / X1 / X2 / Y1 / Y2 / Z1 / Z2

Total tools quantity 26pcs / 14pcs / 40pcs

Modification Dual spindles swiss-type lathe

Machining range diameter (spindle/subspindle) 25.4mm / 25.4mm

Max. processing length 220mm / Removable Rotary Guide Bush

Характеристики

Basic feauturies

Linear axis number 6pcs / X1 / X2 / Y1 / Y2 / Z1 / Z2

Total tools quantity 26pcs / 14pcs / 40pcs

Modification Dual spindles swiss-type lathe

CNC Fanuc 31i-B Plus

Processing parameters

Machining range diameter (spindle/subspindle) 25.4mm / 25.4mm

Max. processing length 220mm / Removable Rotary Guide Bush

Main spindle

Spindle speeds range 10000rpm

C axis 0.001°

Motor power 8.2kW / 10.5kW

Back spindle

Spindle speeds range 10000rpm

C axis 0.001°

Motor power 8.2kW / 10.5kW

Cross driven tools main spindle

Cross driven tools 4pcs / 6000rpm

Cross driven tools 3pcs / 6000rpm

Motor power 1kW

Main spindle O.D. turning tools

Tool seat arrangement Side offset tool holder

Tool number 9pcs

Tool Size 16mm x 16mm

Main spindle end face tools

End-face fixed tools 5pcs

Motor power 1kW

Sub-spindle end face tools

End-face driven tools 4pcs / 6000rpm

End-face fixed tools 9pcs

Motor power 0.75kW

Linear axes

Rapid traverse 35m/min / 35m/min / 35m/min / 35m/min / 35m/min / 35m/min

Other

Water tank capacity 200L

Power of coolant pump motor 0.79kW

Overall dimensions and weight

Weight 3550kg

Overall length 2710mm

Overall width 1270mm

Overall height 1990mm

Комплектация

Товары этой серии

Сравнить товары серии

TORNOS GT

Swiss-type CNC lathe GT 13
