Turning center LT-400M

Серия: LT

Max. swing diameter over bed 400mm

Max. swing over cross slide: 320mm

Spindle speeds range 30rpm — 4000rpm

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

C axis Presence

Capability

Max. swing diameter over bed 400mm

Max. swing over cross slide: 320mm

Distance between centers 645mm

Processing length 530mm

Main spindle

Spindle drive Belt drive

Spindle speeds range 30rpm — 4000rpm

Lathe Spindle Nose A2-6

Spindle bore diameter 63mm

Bar Size 52mm

C-axis (main spindle) resolution 0.001°

Spindle motor power 7.5kW / 11kW

Feeds

X-Axis travel 190mm

X-axis transmission type Ball screw

Z-Axis travel 530mm

Z-axis transmission type Ball screw

Rapid traverse 20000mm/min / 24000mm/min

Feed motor

Power of feed motors

1.8kW

Carriage

Tool post Lathe turret

Tool сhanging time (Adjacent/Farthest) 0.6sec. / 0.8sec.

Tools

Tooling Live tooling

Tools quantity 12pcs

Tool shank 25mm x 25mm

Tool shank diameter 40mm

Motor power 1kW

Live tooling speed 10rpm — 5000rpm

Tailstock

Tailstock Hydraulic

Max. travel of tailstock quill 100mm

Tailstock quill diameter 90mm

Morse cone MT5

Tailstock stroke 435mm

Cutting fluid

Tank capacity 200L

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 4300kg

Overall length 2250mm

Overall width 1770mm

Overall height 1670mm
