Turning center LT-520M

Серия: LT

Max. swing diameter over bed 520mm

Max. swing over cross slide: 400mm

Spindle speeds range 30rpm — 3500rpm

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

C axis Presence

Capability

Max. swing diameter over bed 520mm

Max. swing over cross slide: 400mm

Distance between centers 845mm

Processing length 710mm

Main spindle

Spindle drive Belt drive

Spindle speeds range 30rpm — 3500rpm

Lathe Spindle Nose A2-8

Spindle bore diameter 88mm

Bar Size 78mm

C-axis (main spindle) resolution 0.001°

Spindle motor power 15kW / 18.5kW

Feeds

X-Axis travel 220mm

X-axis transmission type Ball screw

Z-Axis travel 710mm

Z-axis transmission type Ball screw

Rapid traverse 20000mm/min / 20000mm/min

Feed motor

Power of feed motors

1.8kW

Carriage

Tool post Lathe turret

Tool сhanging time (Adjacent/Farthest) 0.6sec. / 0.8sec.

Tools

Tooling Live tooling

Tools quantity 12pcs

Tool shank 25mm x 25mm

Tool shank diameter 40mm

Motor power 1kW

Live tooling speed 10rpm — 5000rpm

Tailstock

Tailstock Hydraulic

Max. travel of tailstock quill 150mm

Tailstock quill diameter 110mm

Morse cone MT5

Tailstock stroke 580mm

Cutting fluid

Tank capacity 230L

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 5000kg

Overall length 2850mm

Overall width 1910mm

Overall height 1800mm
