Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC vertical machining centers (VMC) / Vertical CNC machining center VMC1270
Triple Tech

Vertical CNC machining center VMC1270

Серия: VMC
Working table size 1400mm x 700mm
Max. weight of workpiece 1000kg
Feed travels 1200mm / 700mm / 700mm

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 1400mm x 700mm
T-slots 5pcs / 18mm / 122mm
Max. weight of workpiece 1000kg

Spindle

Distance from axis of vertical spindle to bed guideway 784mm
Distance from vertical spindle nose to surface of working table 80mm / 780mm
Spindle speeds range
8000rpm
8000rpm
10000rpm
Spindle drive
Direct drive
Direct drive
Direct drive
Spindle taper
BT50 / BBT-50
BT50 / BBT-50
BT50 / BBT-50
Spindle motor power
15kW
18.5kW
15kW
Spindle torque
118N⋅m
236N⋅m
118N⋅m

Accuracy

Positioning accuracy 0.01mm / 0.01mm / 0.01mm
Repeatability accuracy 0.005mm / 0.005mm / 0.005mm

Automatic tool changer (ATC)

Max. tool diameter 220mm / 105mm
Max. tool lenght 350mm
Max. tool weight 15kg
Tool сhanging time (Tool-to-Tool) 2.91sec.
Tool magazine capacity
24pcs
30pcs

Feeds

Feed travels 1200mm / 700mm / 700mm
Rapid traverse 24000mm/min / 24000mm/min / 12000mm/min
Power of feed motors 3kW / 3kW / 3kW

CNC

Model Fanuc

Cutting fluid

Water tank capacity 230L
Power of coolant pump motor 0.49kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Other

Lubrication system Full-automatic
Splash guard cover Full splash guard

Overall dimensions and weight

Weight 11000kg
Overall length 3640mm
Overall width 3080mm
Overall height 3000mm
