Triple Tech

Vertical CNC machining center VMC866

Серия: VMC

Working table size 1000mm x 550mm

Max. weight of workpiece 500kg

Feed travels 850mm / 600mm / 600mm

Основная конфигурация

Spindle speeds range

6000rpm

8000rpm

10000rpm

12000rpm

15000rpm

20000rpm

Spindle cooling

Air cooling

Oil cooling

Tool magazine capacity

24pcs

30pcs

Характеристики

Working table

Working table size 1000mm x 550mm

T-slots 5pcs / 18mm / 115mm

Max. weight of workpiece 500kg

Spindle

Distance from axis of vertical spindle to bed guideway 635mm

Distance from vertical spindle nose to surface of working table 140mm / 740mm

Spindle speeds range

6000rpm

8000rpm

10000rpm

12000rpm

15000rpm

20000rpm

Spindle drive

Belt drive

Direct drive

Spindle cooling

Air cooling

Oil cooling

Spindle taper

BT40

BBT-40

Spindle motor power

9kW / 11.25kW

7.5kW / 11kW

11kW / 15kW

9kW / 11.25kW

Spindle torque

60N⋅m

70N⋅m

95.5N⋅m

60N⋅m

Accuracy

Positioning accuracy 0.008mm / 0.008mm / 0.008mm

Repeatability accuracy 0.005mm / 0.005mm / 0.005mm

Automatic tool changer (ATC)

Tool magazine type

Drum-type tool magazine

Tool changing type

With robotic arm

Tool magazine capacity

24pcs

30pcs

Max. tool diameter

150mm / 78mm

Max. tool lenght

300mm

Max. tool weight

7kg

Tool сhanging time (Tool-to-Tool)

2.2sec.

Feeds

Feed travels 850mm / 600mm / 600mm

Rapid traverse 36000mm/min / 36000mm/min / 36000mm/min

Power of feed motors 3kW / 3kW / 3kW

CNC

CNC Fanuc 0i-MF Plus (5)

Model Fanuc 0i-MF Plus (5)

Cutting fluid

Water tank capacity 180L

Power of coolant pump motor 0.49kW

Through spindle coolant

Absence

20bar

70bar

Engines and power supply

Voltage 380V / 50Hz

Other

Lubrication system Full-automatic

Counterweight central guide device Counterweight

Splash guard cover Full splash guard

Electrical cabinet

Fun cooling

With heat exchanger

With aircondition

Overall dimensions and weight

Weight 5600kg

Overall length 2640mm

Overall width 2460mm

Overall height 2910mm

Периферия

Rotary tables

PAR-253R

GXA210S

GXA255H

Tool measuring system

Z-MT

TS27R

Workpiece measurement system

TC50

OMP60

Chip conveyors

Chain Chip conveyor DMTG

Scraper Chip conveyor DMTG
