LIZHU

Vertical injection molding machine LZ-600D

Серия: LZ

Number of heating zones 5pcs

Clamping force 600kN

Platen size 940mm x 500mm

Цена и условия

Цена по запросу

Характеристики

Injection Unit

Number of heating zones 5pcs

Clamping unit

Clamping force 600kN

Max. opening stroke 200mm

Platen size 940mm x 500mm

Thickness of mould 200mm

Space between tie bars 400mm

Ejector stroke 100mm

Ejector force 15kN

Other

Heating power 9.15kW

Tank capacity 260L

Cutting fluid consumption 1l/min

Overall dimensions and weight

Weight 4500kg

Overall length 2700mm

Overall width 1750mm

Overall height 3500mm
