LITZ

Vertical machining center CV-1200A

Серия: CV

Working table size 1220mm x 620mm

Max. weight of workpiece 1000kg

Feed travels 1200mm / 600mm / 675mm

Характеристики

Working table

Working table size 1220mm x 620mm

T-slots 5pcs / 18mm / 100mm

Max. weight of workpiece 1000kg

Spindle

Spindle drive Belt drive

Spindle motor power 15kW / 18.5kW

Distance from vertical spindle nose to surface of working table 100mm / 775mm

Spindle taper

BT40

Automatic tool changer (ATC)

Tool magazine type Drum-type tool magazine

Tool changing type Direct-to-Spindle tool changing

Max. tool diameter 125mm / 80mm

Max. tool lenght 300mm

Max. tool weight 7kg

Tool magazine capacity

24pcs

30pcs

32pcs

40pcs

Feeds

Feed travels 1200mm / 600mm / 675mm

Max. speed of traverse feeds 20000mm/min / 20000mm/min / 20000mm/min

Rapid traverse 24000mm/min / 24000mm/min / 18000mm/min

Power of feed motors 2.0kW / 2.0kW / 2.0kW

X/Y guideways type Linear guidway

Z-axis guideway type Linear guidway

X-axis transmission type Ball screw

Y-axis transmission type Ball screw

Z-axis transmission type Ball screw

Cutting fluid

Water tank capacity 360L

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Chip and dust removal systems

Chip carrier Presence

Other

Splash guard cover Full splash guard

Overall dimensions and weight

Weight 7000kg

Overall length 2240mm

Overall width 2735mm

Overall height 3007mm
