Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC vertical machining centers (VMC) / Vertical machining center CV-1200B
LITZ

Vertical machining center CV-1200B

Серия: CV
Working table size 1220mm x 620mm
Max. weight of workpiece 1200kg
Feed travels 1200mm / 600mm / 675mm

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 1220mm x 620mm
T-slots 5pcs / 18mm / 100mm
Max. weight of workpiece 1200kg

Spindle

Spindle drive Belt drive
Spindle taper BT50
Spindle motor power 15kW / 18.5kW
Distance from vertical spindle nose to surface of working table 100mm / 775mm

Automatic tool changer (ATC)

Tool magazine type Drum-type tool magazine
Tool changing type Direct-to-Spindle tool changing
Max. tool diameter 125mm / 80mm
Max. tool lenght 300mm
Max. tool weight 8kg
Tool magazine capacity
24pcs
30pcs
32pcs
40pcs

Feeds

Feed travels 1200mm / 600mm / 675mm
Max. speed of traverse feeds 20000mm/min / 20000mm/min / 20000mm/min
Rapid traverse 24000mm/min / 24000mm/min / 18000mm/min
Power of feed motors 3.5kW / 3.5kW / 3.5kW
X/Y guideways type Linear guidway
Z-axis guideway type Linear guidway
X-axis transmission type Ball screw
Y-axis transmission type Ball screw
Z-axis transmission type Ball screw

Cutting fluid

Water tank capacity 360L

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Chip and dust removal systems

Chip carrier Presence

Other

Splash guard cover Full splash guard

Overall dimensions and weight

Weight 7000kg
Overall length 2240mm
Overall width 2735mm
Overall height 3007mm

Периферия

Automatic barfeeders

XT 320 S2 (3.2)
XT 320 S2 (3.2)
Bar Size : 26mm , Max. bar lenght : 3200mm

Chamfering machines

DJ-80P
DJ-80P
Clamping system : 3-jaw chuck / Pneumatic , Bar Size : 10mm — 45mm , Outer diameter of pipe : 10mm — 80mm , Spindle speeds : 800rpm / 1600rpm , Cutter head diameter : 12mm — 18mm
DJ-80H
DJ-80H
Clamping system : 3-jaw chuck / Full-automatic / Hydraulic , Bar Size : 10mm — 60mm , Outer diameter of pipe : 10mm — 80mm , Spindle speeds : 800rpm / 1600rpm , Spindle motor power : 0.73kW / 1pcs , Cutter head diameter : 12mm — 18mm

Комплектация

3-axes coolant thru ballscrew (CTB)
3-axes linear roller guideway
3-axes linear scale
Air blow gun
Air-conditioner for electrical cabinet
Air reservoir system
Automatic voltage stabilizer
CE specifications
Chip cart
Coolant gun
Coolant splash ring for spindle
Counter weight central guide device
Deep hole drilling block and oil cutter handle
Front Door Safety System
Full protection cover
Heater exchanger for electrical cabinet
M30 automatic power off system
Machine oil/coolant separation system
Manual Pulse Generator (MPG)
Rigid tapping function
Screw chip conveyor
Spindle dust-proof air-sealing system
Spindle external programmable air blow system
Spindle head coolant cooling system
Status tower light
Tool breakage detection
Tool length measurement system
Tool shelf and tool cabinet
Wash down device
Workpiece measurement system
Z-axis brake motor system
Х/Y/Z axis bellows
