Sodick

Wire cut EDM ALN400Gs

Серия: ALN

X/Y-Axis travel 400mm / 300mm

Z-Axis travel 250mm

U-Axle travel 150mm

V-Axle travel 150mm

Основная конфигурация

Max. weight of workpiece

350kg

500kg

Цена и условия

Цена по запросу

Характеристики

Machine unit

Work tank inner size 850mm x 610mm

Max. taper angle 25° / 130mm

Wire diameter 0.05mm — 0.3mm

Wire feeding speed 25m/min

Wire tension 3gf — 23gf

Machining method

Submerge

Flushing type

Max. workpiece dimensions

600mm x 470mm x 230mm

600mm x 470mm x 240mm

Max. weight of workpiece

350kg

500kg

CNC

Software Windows based

Controlled axis X-axis / Y-axis / Z-axis / U-axis / V-axis

Display 19″ / TFT LCD

Feeds

X/Y-Axis travel 400mm / 300mm

Z-Axis travel 250mm

U-Axle travel 150mm

V-Axle travel 150mm

Max. speed of traverse feeds 3000mm/min / 3000mm/min / 2000mm/min

Pulse generator

Operating current

40A

60A

Dielectric fluid unit

Tank capacity 792L

Filter type Paper filter

Overall dimensions 775mm x 2250mm x 2202mm

Weight 450kg

Other

X-axis drive Linear motor

Y-axis drive Linear motor

U-axis drive Linear motor

V-axis drive Linear motor

Overall dimensions and weight

Weight 3200kg

Overall length 2190mm

Overall width 2425mm

Overall height 2205mm
