Sodick

Wire cut EDM ALN600Gs

Серия: ALN

Max. weight of workpiece 1000kg

X/Y-Axis travel 600mm / 400mm

Z-Axis travel 350mm

U-Axle travel 150mm

V-Axle travel 150mm

Цена и условия

Цена по запросу

Характеристики

Machine unit

Work tank inner size 1050mm x 710mm

Max. weight of workpiece 1000kg

Max. taper angle 25° / 130mm

Wire diameter 0.05mm — 0.3mm

Wire feeding speed 25m/min

Wire tension 3gf — 23gf

Machining method

Submerge

Flushing type

Max. workpiece dimensions

800mm x 570mm x 280mm

800mm x 570mm x 340mm

CNC

Software Windows based

Controlled axis X-axis / Y-axis / Z-axis / U-axis / V-axis

Display 19″ / TFT LCD

Feeds

X/Y-Axis travel 600mm / 400mm

Z-Axis travel 350mm

U-Axle travel 150mm

V-Axle travel 150mm

Max. speed of traverse feeds 3000mm/min / 3000mm/min / 2000mm/min

Pulse generator

Operating current

40A

60A

Dielectric fluid unit

Tank capacity 1001L

Filter type Paper filter

Overall dimensions 870mm x 2605mm x 2179mm

Weight 500kg

Other

X-axis drive Linear motor

Y-axis drive Linear motor

U-axis drive Linear motor

V-axis drive Linear motor

Overall dimensions and weight

Weight 4300kg

Overall length 2525mm

Overall width 2735mm

Overall height 2295mm
