13-axis CNC spring forming machine ST80-13R (JOINT), China at a bargain price with delivery to any region on the Knavi website.

Характеристики

Basic feauturies

Quantity of controlled axis 12pcs

Type of spring Tension / Torsion / Double torsion / Wire bending

Spring-forming machine variation Сamless machine

CNC

CNC language Chinese / English

Processing parameters

Wire diameter 3mm — 8mm

Direction of coiling Right + Left

Wire feeding speed 80m/min

Wire feed value 0.01mm — 10000mm

Wire feeder

Loading weight 1500kg

Controlled axes

Sliders axis 8pcs x 4.5kW

Wire feed axis 1pcs x 15kW

Core axis 1pcs x 1.8kW

Wire rotary axis 1pcs x 4.5kW

Spinner 1pcs x 2.7kW

Servo shears 1pcs x 1.3kW

Engines and power supply

Total motor power 60kW

Voltage 380V / 50Hz

Overall dimensions and weight

Weight 6000kg

Overall length 3700mm

Overall width 2150mm

Overall height 2100mm

Периферия

Servo shears

Servo-shears ST80-13R

Spinner

Joint_Spinner_ST80-13R

Free arm

Joint FreeArm _ST60-12R _ST80-13R
