Machine tools and equipment / Metalworking machine tools / CNC machining centers / 5-Axis CNC Machining Center / 5-Axis CNC Machining Center M2-5AX
Hwacheon

5-Axis CNC Machining Center M2-5AX

Серия: 5AX
Working table size 500mm
Max. weight of workpiece 300kg
Feed travels 750mm / 650mm / 500mm
A-axis Tilting Angle 30° ~ -120°
Rotation range of C-axis 360°
Tool magazine capacity 30pcs

Основная конфигурация

Spindle speeds range
20000rpm
30000rpm

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 500mm
T-slots 5pcs / 14mm / 80mm
Max. weight of workpiece 300kg

Feeds

Feed travels 750mm / 650mm / 500mm
A-axis Tilting Angle 30° ~ -120°
Rotation range of C-axis 360°
Max. speed of traverse feeds 24000mm/min
Rapid traverse 50000mm/min / 50000mm/min / 50000mm/min / 8.3rpm / 33.3rpm
Power of feed motors 4kW / 7kW / 4kW

Spindle

Spindle taper ISO40
Distance from vertical spindle nose to surface of working table 75mm / 575mm
Spindle speeds range
20000rpm
30000rpm
Spindle bore diameter
70mm
45mm
Lathe Spindle Nose
BBT-40
HSK-E40
Spindle motor power
18.5kW / 37kW
13kW / 18.5kW

Automatic tool changer (ATC)

Tool magazine capacity 30pcs
Max. tool diameter 170mm / 80mm
Max. tool lenght 300mm
Max. tool weight 8kg

CNC

CNC model Fanuc 31i-B5

Cutting fluid

Water tank capacity 400L
Power of coolant pump motor 0.4kW

Engines and power supply

Total motor power 65kW
Compressed Air Supply 0.6MPa х 690l/min
Voltage 380V / 50Hz

Overall dimensions and weight

Weight 11000kg
Overall length 3025mm
Overall width 3695mm
Overall height 3090mm
