Hwacheon

5-Axis CNC Machining Center M3-5AX

Серия: 5AX

Working table size 700mm

Max. weight of workpiece 800kg

Feed travels 750mm / 900mm / 550mm

A-axis Tilting Angle 120° ~ 120°

Rotation range of C-axis 360°

Основная конфигурация

Spindle speeds range

14000rpm

20000rpm

24000rpm

Tool magazine capacity

40pcs

60pcs

90pcs

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 700mm

T-slots 5pcs / 18mm / 100mm

Max. weight of workpiece 800kg

Feeds

Feed travels 750mm / 900mm / 550mm

A-axis Tilting Angle 120° ~ 120°

Rotation range of C-axis 360°

Rapid traverse 48000mm/min / 48000mm/min / 40000mm/min / 30rpm / 40rpm

Power of feed motors 7kW / 4kW / 7kW

Spindle

Spindle taper ISO40

Distance from vertical spindle nose to surface of working table 140mm / 690mm

Spindle speeds range

14000rpm

20000rpm

24000rpm

Spindle bore diameter

70mm

Lathe Spindle Nose

BBT-40

Spindle motor power

22kW / 37kW

18.5kW / 37kW

Automatic tool changer (ATC)

Taper size BBT-40

Max. tool diameter 160mm / 80mm

Max. tool lenght 320mm

Max. tool weight 8kg

Tool magazine capacity

40pcs

60pcs

90pcs

CNC

CNC model Fanuc 31i-B5

Cutting fluid

Water tank capacity 550L

Power of coolant pump motor 0.4kW

Engines and power supply

Total motor power 100kW

Compressed Air Supply 0.6MPa х 690l/min

Voltage 380V / 50Hz

Overall dimensions and weight

Weight 21000kg

Overall length 4100mm

Overall width 6595mm

Overall height 3855mm
