6 axis spring coiling machine JTC 680 (JOINT), China at a bargain price with delivery to any region on the Knavi website.

Характеристики

Basic feauturies

Quantity of controlled axis 6pcs

Type of spring Compression / Torsion

CNC

Spring coiling machine computer Windows based

CNC language Chinese / English

Interactive programming

Yes

Processing parameters

Spring diameter 150mm

Wire diameter 3mm — 8mm

Wire feed value 0.01mm — 10000mm

Wire feeding speed 70m/min

Direction of coiling Right + Left

Wire feeder

Loading weight 2000kg

Controlled axes

OD control axis 5.5kW / 5.5kW

Pitch axis 1pcs x 4.5kW

Wire feed axis 1pcs x 30kW

Cutting axis 5.5kW / 5.5kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Total motor power 56.5pcs

Overall dimensions and weight

Weight 5000kg

Overall length 2250mm

Overall width 2100mm

Overall height 2500mm

Периферия

Spring length detector

CXYX-1

Wire feeders

JTC-2000

Комплектация

Diamond needle files

Количество: 1 set

Manual lubrication of guides

Pneumocylinder

Количество: 1 pcs

Probe

Количество: 2 pcs

Tools box

Инструмент и оснастка для навивки

Количество: 1 set

4.5mm / 5.0mm / 5.5mm / 6.0mm / 6.5mm / 7.0mm / 7.5mm / 8.0mm

Лампа освещения рабочей зоны
