Machine tools and equipment / Bending and forming machinery / Wire forming machinery / Spring coiling machines / 9 axis spring coiling machine JTC 980
JOINT

9 axis spring coiling machine JTC 980

Серия: JTC 9
Quantity of controlled axis 9pcs
Wire diameter 3mm — 8mm
Wire feed value 0.01mm
Wire feeding speed 70m/min

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Quantity of controlled axis 9pcs
Type of spring Compression / Torsion

CNC

Spring coiling machine computer Windows based
CNC language Chinese / English
Interactive programming
No
Yes

Processing parameters

Wire diameter 3mm — 8mm
Wire feed value 0.01mm
Wire feeding speed 70m/min
Direction of coiling Right + Left
Wire feeding wheel pressing mode Pneumatic

Wire feeder

Loading weight 1500kg

Controlled axes

Outer diameter control mode Two curves (individual motor control)
OD control axis 5.5kW / 5.5kW / 4.5kW
Arbor moving axis 2.7kW / 4.5kW
Pitch axis 1pcs x 4.5kW
Wire feed axis 1pcs x 30kW
Cutting axis 5.5kW / 5.5kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 5000kg
Overall length 2250mm
Overall width 2100mm
Overall height 2500mm

Периферия

Wire feeders

JTC-1500
JTC-1500

Spring length detector

CXYX-1
CXYX-1

Комплектация

Diamond needle files
Количество: 1 set
Grease gun
Количество: 1 pcs
Left-direction coiling knife rest
Manual lubrication of guides
Oil gun
Количество: 1 pcs
Pneumocylinder
Количество: 1 pcs
Probe
Количество: 2 pcs
Right-direction coiling knife rest
Tools box
Количество: 1 pcs
Torsion spring making unit
Инструмент и оснастка для навивки
Количество: 1 set
Лампа освещения рабочей зоны
Количество: 1 pcs
