Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC vertical machining centers (VMC) / CNC Dual Table Vertical Machining Center VESTA-610D
Hwacheon

CNC Dual Table Vertical Machining Center VESTA-610D

Серия: VESTA
Working table size 650mm x 450mm
Max. weight of workpiece 300kg
Tool magazine capacity 24pcs
Feed travels 610mm / 430mm / 570mm

Основная конфигурация

Spindle speeds range
10000rpm
12000rpm
15000rpm

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 650mm x 450mm
T-slots 3pcs / 18mm / 150mm
Max. weight of workpiece 300kg

Spindle

Distance from vertical spindle nose to surface of working table 150mm / 720mm
Spindle speeds range
10000rpm
12000rpm
15000rpm
Spindle drive
Direct drive
Direct drive
Direct drive
Spindle taper
ISO40
ISO40
ISO40
Spindle motor power
7.5kW / 11kW
11kW / 18.5kW
11kW / 18.5kW

Automatic tool changer (ATC)

Tool magazine capacity 24pcs
Max. tool diameter 150mm / 90mm
Max. tool lenght 300mm
Max. tool weight 8kg
Tool сhanging time (Tool-to-Tool) 1.5sec.

Feeds

Feed travels 610mm / 430mm / 570mm
Min. speed of traverse feeds 1mm/min / 1mm/min / 1mm/min
Max. speed of traverse feeds 24000mm/min / 24000mm/min / 24000mm/min
Rapid traverse 40000mm/min / 40000mm/min / 40000mm/min
Power of feed motors 7kW / 7kW / 7kW

CNC

Model Fanuc 0i-MF

Cutting fluid

Water tank capacity 395L
Power of coolant pump motor 0.4kW

Engines and power supply

Total motor power 50kW
Compressed Air Supply 0.6MPa х 690l/min
Voltage 380V / 50Hz

Overall dimensions and weight

Weight 7500kg
Overall length 4130mm
Overall width 2120mm
Overall height 2670mm
