Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC vertical machining centers (VMC) / Vertical CNC machining center VESTA-850B
Hwacheon

Vertical CNC machining center VESTA-850B

Серия: VESTA
Working table size 1050mm x 600mm
Max. weight of workpiece 800kg
Feed travels 850mm / 600mm / 600mm

Основная конфигурация

Spindle speeds range
8000rpm
6000rpm
Tool magazine capacity
24pcs
30pcs

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 1050mm x 600mm
T-slots 5pcs / 18mm / 120mm
Max. weight of workpiece 800kg

Spindle

Distance from vertical spindle nose to surface of working table 125mm / 725mm
Spindle speeds range
8000rpm
6000rpm
Spindle taper
ISO40
ISO50
Spindle motor power
15kW / 18.5kW
15kW / 18.5kW

Automatic tool changer (ATC)

Tool magazine capacity
24pcs
30pcs

Feeds

Feed travels 850mm / 600mm / 600mm
Min. speed of traverse feeds 1mm/min / 1mm/min / 1mm/min
Max. speed of traverse feeds 10000mm/min / 10000mm/min / 10000mm/min
Rapid traverse 24000mm/min / 24000mm/min / 18000mm/min
Power of feed motors 3kW / 3kW / 3kW

CNC

Model Fanuc 0i-MF

Cutting fluid

Water tank capacity 340L
Power of coolant pump motor 0.4kW

Engines and power supply

Compressed Air Supply 0.6MPa х 690l/min
Voltage 380V / 50Hz

Overall dimensions and weight

Weight 6970kg
Overall length 3870mm
Overall width 2247mm
Overall height 2718mm
