Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC vertical machining centers (VMC) / Vertical CNC machining center VESTA-1000+
Hwacheon

Vertical CNC machining center VESTA-1000+

Серия: VESTA
Working table size 1100mm x 502mm
Max. weight of workpiece 700kg
Tool magazine capacity 30pcs
Feed travels 1000mm / 550mm / 500mm

Основная конфигурация

Spindle speeds range
10000rpm
12000rpm
15000rpm

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 1100mm x 502mm
T-slots 5pcs / 18mm / 80mm
Max. weight of workpiece 700kg

Spindle

Distance from vertical spindle nose to surface of working table 130mm / 630mm
Spindle speeds range
10000rpm
12000rpm
15000rpm
Spindle drive
Direct drive
Direct drive
Direct drive
Spindle taper
ISO40
ISO40
ISO40
Spindle motor power
11kW / 18.5kW
11kW / 18.5kW
11kW / 18.5kW

Automatic tool changer (ATC)

Tool magazine capacity 30pcs
Max. tool diameter 150mm / 75mm
Max. tool lenght 300mm
Max. tool weight 8kg
Tool сhanging time (Tool-to-Tool) 2.5sec.

Feeds

Feed travels 1000mm / 550mm / 500mm
Min. speed of traverse feeds 1mm/min / 1mm/min / 1mm/min
Max. speed of traverse feeds 24000mm/min / 24000mm/min / 24000mm/min
Rapid traverse 36000mm/min / 36000mm/min / 30000mm/min
Power of feed motors 1.8kW / 1.8kW / 3kW

CNC

Model Fanuc-0i MD

Cutting fluid

Water tank capacity 250L
Power of coolant pump motor 0.4kW

Engines and power supply

Compressed Air Supply 0.6MPa х 690l/min
Voltage 380V / 50Hz

Overall dimensions and weight

Weight 5040kg
Overall length 2850mm
Overall width 2420mm
Overall height 2642mm
