Machine tools and equipment / Metalworking machine tools / Electrical discharge machines (EDM) / CNC-EB EDM / CNC-EB EDM CNC-EB3010L-2H
JSedm

CNC-EB EDM CNC-EB3010L-2H

Серия: EB
Working table size 3100mm x 1100mm
X-Axis travel 2550mm / Single-Axis
X-Axis travel 1275mm / Dual-Axis
Y-Axis travel 1000mm
Z-Axis travel 600mm
Max. weight of workpiece 16000kg

Цена и условия

Цена по запросу

Характеристики

Machine unit

Die-sink EDM Machine design Ram-type
Working table size 3100mm x 1100mm
Work tank inner size 3900mm x 1700mm x 800mm
X-Axis travel 2550mm / Single-Axis
X-Axis travel 1275mm / Dual-Axis
Y-Axis travel 1000mm
Z-Axis travel 600mm
Max. weight of workpiece 16000kg
Distance between table surface and electrode plate 1320mm
Max. electrode weight 500kg

Dielectric fluid unit

Tank capacity 5800L
Filter type Paper filter / 2pcs

Pulse generator

Operating current 120A
Max.material removal rate 400mm³/min
Electrode wear rate 0.12%

Accuracy

Best surface roughness 0.2μm/Ra

CNC

Software Windows based
EDM system CNC
Controlled axis X-axis / Y-axis / Z-axis
Setting limits 0.001mm
Display 15″ / TFT LCD

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 21000kg
Overall length 7000mm
Overall width 4600mm
Overall height 3620mm

Комплектация

Auto. Tool change
C axis
Chiller
EROWA clamping tool
Filter
Количество: 2 pcs
Fire extinguisher
Количество: 1 pcs
Full-automatic
+GF+ System 3R Clamping tools
Magnetic chuck
Tools box
Количество: 1 pcs
Лампа освещения рабочей зоны
Количество: 1 pcs
